Veneer Stacking Machine

 /4ft Automatic plywood veneer stacker - Two stack

4ft Automatic Vaccum Veneer Stacker
4ft Automatic Vaccum Veneer Stacker 4ft Automatic Vaccum Veneer Stacker 4ft Automatic Vaccum Veneer Stacker

4ft Automatic plywood veneer stacker - Two stack

4ft Automatic plywood veneer stacker - Two stack

1.This machine will sort and stack the wood veneer automatically after spindless wood veneer peeling. It save labor cost and improving working efficiency.

2.The machine can clarify and pile up low quality,middle quality and high quality veneer.




  • Item NO.:

    BDD1113BI

  • Lead Time:

    30 days after receipt of advance payment

  • Product origin:

    CHINA

  • Shipping Port:

    Fuzhou,China

  • Payment:

    T/T, L/C

  • Color:

    Dark Green or Customized
Inquire now
  • Product Detail

Product Name :4ft Automatic plywood veneer stacker - Two stack

This machine can separate the waste and good quality wood veneer automatically.

Major Technical Parameters

Stacking veneer width: 1270(1300)

Stacking veneer length: 680-270mm

Stacking veneer thickness : 0.8-4.0 mm

Elevation way: Hydraulic lift

Veneer stacking classification: 1,2,3

Veneer transfer type after stacking: Chain automatic transfer

Air blower specification and number: 2.2KW*6

Air blower: Inverter

Total power: 30.7 KW

Overall Dimensions:14000*1400


Features:

1 .Labor Saving
2. High efficiency
3. Customize is available
4. Adapt to different veneer and plywood manufacture
5. A user-friendly structure helps the operators spot any problems.
( Design production line or link with your own production)
