Heavy type 4ft Spindleless Veneer Peeling Machine high speed

BQ1813/E4-J is a stable model of  Heavy type 4FT Core Veneer Making Machine. It is used to peel small log then make wood veneer. The Spindleless veneer peeling lineis a part of 4x8 Plywood making making .We could manufacture 4ft,6ft ,8ft CNC spindleless veneer peeling machine or customized ones.
  • Item NO.:

    BQ1813/E4-J
  • Lead Time:

    30 days after receipt of advance payment
  • Product origin:

    CHINA
  • Shipping Port:

    Fuzhou,China
  • Payment:

    T/T, L/C
  • Color:

    Dark Green or Customized
  • Product Detail

Product Name:  Heavy type 4ft Spindleless Veneer Peeling Machine high speed

Major Technical Parameters

Model : BQ1813/E4-J

Length of Veneer Log: 900-1400mm

Diameter of Veneer Log: Φ30-Φ400mm

Length of Peeling Knife: 1500mm

Thickness of Veneer: 0.5-4.0mm

Width of Veneer: 300-3000

Linear Speed of Veneer Peeling Line:  53/65/80m/min

Total Power:  37.5/41.5KW

Total Weight:  6500kg

Overall Dimensions: 4010*2300*1550

Main Advantages

1.     An advanced CNC system ensures the tolerance of wood veneer which is peeled by wood veneer machine.

2.     Adjusted veneer peeling knife makes the big diameter log processing easily.

3.     The text display helps the operator to adjust and operate the wood veneer machine easily.

4.     The operators can change the wood veneer thickness during the rotary veneer peeling without stopping the veneer machine.

5.     A two-in-one structure,veneer peeling and veneer cutting together, which will save cost and labors.

1300mm poplar wood veneer peeling machine

4ft High Speed poplar wood veneer peeling machine

4ft core poplar veneer peeling machine

poplar wood debarking machine

poplar tree debarker machine supplier Why Choose Us

1.     We are factory of veneer peeling machine

More than 20 years of experience in design and produce veneer peeling machine

Suitable price, good quality and best service

2.     We provide best service

Pre-sale: provide the free consultation of the equipment.

During the sale: inspect the machine before leaving the factory.

After the sale:24 hours online services and send engineer for the veneer peeling machine installation
