Product Name: China Spindleless Veneer PeelingMachine/wood peeler
Major Technical Parameters:
|
DESCRIPTION |
UNIT |
BQ1813/G6S-J
General |
|
Length of log |
mm |
900-1400 |
|
Diameter of log |
mm |
Φ30-Φ650 |
|
Length of blade |
mm |
1500 |
|
Thickness of veneer |
mm |
0.8-4.0 |
|
Width of cut veneer |
mm |
500-1300 |
|
Linear speed of host machine |
m/min |
60 m/min
|
|
Diameter of driving roller |
mm |
115 |
|
Diameter of pressure bar roller |
mm |
116 |
|
Diameter of rubber roller |
mm |
140 |
|
Power of pressure bar roller |
KW |
15 |
|
Power of double roller |
KW |
15 |
|
Power of cutting feed |
KW |
15 |
|
Power of shear |
KW |
3 |
|
Power of output converyor |
KW |
1.5 |
|
Total power |
KW |
49.5 |
|
Total weight |
kg |
6500 |
|
Overall dimensions |
mm |
3700*2800*1700 |
Main Features:
1. Wood rotary lathe and cutting wood veneer all in one.
2. Simple operation & easy maintenance ; the quality of wood veneer thickness similar to that of veneer peeled by the spindle rotary peeling machine.
3. Upgraded technology guarantee the flatness, evenness and smoothness of different thickness veneer
4. Special self-made drive reducer according to the structure and speed of Spindleless veneer peeling machine
