Log 400mm-Heavy duty 8ft plywood veneer peeling lathe

BQ1826/D4S is a heavy type model of 8FT Face Veneer Machine. It is used to peel 400mm log then make good quality wood face veneer. The Spindlelessveneer plywood machineis a part of 4x8 Plywood manufacture machine. We manufacture 4ft,6ft ,8ft CNC spindleless veneer peeling machine or customized ones.

  • Item NO.:

    BQ1826/D4S
  • Lead Time:

    30 days after receipt of advance payment
  • Product origin:

    CHINA
  • Shipping Port:

    Fuzhou,China
  • Payment:

    T/T, L/C
  • Color:

    Dark Green or Customized
  • Product Detail

Product Name: Log 400mm- 8ft Spindleless Veneer Peeling Machine BQ1826/D4S

Major Technical Parameters

Model : BQ1826/D6S

Length of Veneer Log: 2000-2600mm

Diameter of Veneer Log: Φ40-Φ400mm

Length of Peeling Knife: 2750mm

Thickness of Veneer: 0.5-3.6mm

Linear Speed of Veneer Peeling Line:  400m/min

Total Power: 59KW

Total Weight:  16000kg

Overall Dimensions: 4750*2000*1900

Main Advantages

1.     An advanced CNC system ensures the tolerance of wood veneer which is peeled by wood veneer machine.

2.     Adjusted veneer peeling knife makes the big diameter log processing easily.

3.     The text display helps the operator to adjust and operate the wood veneer machine easily.

4.     The operators can change the wood veneer thickness during the rotary veneer peeling without stopping the veneer machine.

5.     A two-in-one structure,veneer peeling and veneer cutting together, which will save cost and labors.

beech wood veneer peeling

poplar wood veneer lathe

birch wood rotary veneer lathe

4ft Spindleless veneer peeling lathe factory



4ft Core veneer peeling line manufacturer

Why Choose Us

1.   We are factory of veneer peeling machine

More than 20 years of experience in design and produce veneer peeling machine

Suitable price, good quality and best service

2.    We provide best service

Pre-sale: provide the free consultation of the equipment.

During the sale: inspect the machine before leaving the factory.

After the sale:24 hours online services and send engineer for the veneer peeling machine installation
