Spindleless high speed Automatic wood core veneer peeling machine

Spindleless high speed Automatic wood core veneer peeling machine is used to peel log without skin to core veneer and continue peeling log core after spindle peeing. It is very popular for plywood industry.
  • Item NO.:

    BQ1826/ G5GS-JD
  • Lead Time:

    30 days after receipt of advance payment
  • Product origin:

    CHINA
  • Shipping Port:

    Fuzhou,China
  • Payment:

    T/T, L/C
  • Color:

    Dark Green or Customized
  • Product Detail

Product Name:Spindleless high speed Automatic wood core veneer peeling machine

Major Technical Parameters


DESCRIPTION

          UNIT

                   BQ1826/G5GS-JD

Length of log

 mm

2000~2600

Diameter of log

  mm

32~550

Length of blade

  mm

2750

Thickness of veneer

  mm

0.3~3.6

Width of cut veneer

  mm

620~1300

Linear speed of host machine

  m/min

45m/min

83m/min

Diameter of driving roller

mm

115

Diameter of pressurebar roller

mm

116

Diameter of rubber roller

mm

342

Power ofpressurebar roller

KW

11*2

15*2

Power of doubleroller

KW

11*2

15*2

Power of cutting feed

KW

15

Power of shear

KW

7.5

Power of PU roller/

output converyor

KW

7.5

Total power

KW

74

90

Total weight

kg

13000

Overall dimensions

mm

6000*3050*7900


Main Features:

1. High performance CNC system control feeding. The board is smooth, with high productivity.

2. The feeding system adopts the screw and screw nuts. The screw nuts adopt the magnesium aluminum alloy, copper and other materials. So it is with long service life.

3. Automatic adjustment of cutting system, skin is much more uniform and smooth. Apply to woods with different diameters.

4. During the rotary cutting production, the machine can adjust the thickness of two kinds of veneer constantly and won't cause the crack of the veneers.

5. Block type screw and slider, high-precision and energy-saving.

6. The NC rotary and leather cutting are in one, so the machine is with high productivity and labor-saving.
