Hydraulic Barking Machines

 /

4ft Hydraulic Debarker Machine

 /4ft hydraulic debarker machine for plywood veneer making

Rotary debarking machine
Rotary debarking machine

4ft hydraulic debarker machine for plywood veneer making

4ft hydraulic debarker machine for plywood veneer making is used for rounding log and remove the bark before peeling veneer. it is suitable for the eucalyptus, pine, rubber wood,sengon,maranti and other trees.

  • Item NO.:

    BQ1813/6YF

  • Lead Time:

    30 days after receipt of advance payment

  • Product origin:

    CHINA

  • Shipping Port:

    Fuzhou,China

  • Payment:

    T/T, L/C

  • Color:

    Dark Green or Customized
Inquire now
  • Product Detail

Product Name: 4ft hydraulic debarker machine for plywood veneer making

Major Technical Parameters

Model : BQ1813/6YF

Length of  Veneer Log: 100-1300mm

Diameter of Veneer Log: Φ60-Φ600mm

Length of Peeling Knife: 1500mm

Linear Speed of Veneer Peeling Line:  60 m/min

Total Power:  29.5KW

Total Weight:  5500kg

Overall Dimensions: 4000*2000*1714

Product overview:

Before wood veneer peeling, removing the log's skin and making wood straight. Hydraulic drived feed mechanism can quickly and efficiently put log in and remove bark then make wood get around. One set debarker can supply 2 set of veneer peeling machines .
It greatly saves the labor cost and the space.

plywood peeling machine manufacturer

meranti wood veneer machine

plywood making machine

hot press machine supplier for plywood


hot press machine manufacturer for plywood

Leave Message
If you are interested in our products and want to know more details,please leave a message here,we will reply you as soon as we can.
Contact Us
Related Products
4ft Veneer making machine to peel and stick veneer
Log 500mm 4ft Hydraulic Barking Machine
BQ1813/5YC is a model of 4FT Hydraulic barking machine. It is used to peel  the bark of small log then make wood veneer. The Spindleless veneer peeling line is a part of Plywood making making.We could manufacture 4ft,6ft ,8ft CNC spindleless veneer peeling machine or customized ones.
4ft Veneer making machine to peel and stick veneer
Log 600mm 4ft Hydraulic Barking Machine
BQ1813/6YD is a model of 4FT Hydraulic barking machine. It is used to peel  the bark of small log then make wood veneer. The Spindleless veneer peeling line is a part of Plywood making making.We could manufacture 4ft,6ft ,8ft CNC spindleless veneer peeling machine or customized ones.
Log peeling machine
Plywood log debarker and rounding machine
Plywood wood debarker is used to remove the bark of wood and make the wood round before peeling veneer.The wood log after debarking has higher veneer quality and avoid to damage veneer peeling machine knife.
Woodworking knife grinding machine
4ft Knife grinding machine plywood machinery
1. All kind of long knives, like peeling machine knife, cutting machine knife can be grinded by this machine 2. This machine’s body is a design of gantry body, with the high-quality steel weld, stress relieved eliminating the internal stress. The machine body has high strength and good rigidity. 3. The grinding head use the dedicated motor. It can 1
China peeling machine
China Spindleless Veneer PeelingMachine/wood peeler
China Spindleless Veneer PeelingMachine/wood peeler will peel off the log to a think or thick veneer to make artificial panel such as plywood after remove the bark by log debarker.
8ft Spindleless veneer making machine to peel and stick veneer
Log 600mm- 8ft China Plywood Machine Veneer Spindleless Peeling Machine
BQ1826/D6S is a heavy duty model of 8FT Face Veneer Machine for peeling max 600mm log.This machine can be used to peel good quality face wood veneer for high quality plywood manufacture, such as (Plywood flooring, container plywood).This machine is stable and semi-automatic.
spindleless veneer peeling machine for plywood/veneer machine
100m/min High Speed Spindleless Wood Lathe Machine/Rotary Lathe/Veneer Lathe
100m/min High Speed Spindleless Wood Lathe Machine/Rotary Lathe/Veneer Lathe will peel off small diameter (max diameter to 650mm) wood to pieces of veneer.  It combines automatic veneer peeling and rotary veneer clipper in one machine. Veneer size can be set to change.
4ft Spindleless veneer making machine to peel and stick veneer
Heavy duty 4ft Spindleless Hydraulic Wood Veneer Peeling Machine
BQ1813/E6S is a heavy duty Face & Core Veneer plywood machine.This model is to peel big log (max 600mm) and hard wood( Indonesia rubber wood, India eucalyptus, Pakistan eucalyptus and Africa hard wood) .We could manufacture 4ft,6ft ,8ft CNC spindleless veneer peeling machine or customized ones.
