4ft Hydraulic Debarker Machine

 /4ft hydraulic debarker machine for plywood veneer making

Rotary debarking machine
Rotary debarking machine

4ft hydraulic debarker machine for plywood veneer making

4ft hydraulic debarker machine for plywood veneer making is used for rounding log and remove the bark before peeling veneer. it is suitable for the eucalyptus, pine, rubber wood,sengon,maranti and other trees.

  • Item NO.:

    BQ1813/6YF

  • Lead Time:

    30 days after receipt of advance payment

  • Product origin:

    CHINA

  • Shipping Port:

    Fuzhou,China

  • Payment:

    T/T, L/C

  • Color:

    Dark Green or Customized
Inquire now
  • Product Detail

Product Name: 4ft hydraulic debarker machine for plywood veneer making

Major Technical Parameters

Model : BQ1813/6YF

Length of  Veneer Log: 100-1300mm

Diameter of Veneer Log: Φ60-Φ600mm

Length of Peeling Knife: 1500mm

Linear Speed of Veneer Peeling Line:  60 m/min

Total Power:  29.5KW

Total Weight:  5500kg

Overall Dimensions: 4000*2000*1714

Product overview:

Before wood veneer peeling, removing the log's skin and making wood straight. Hydraulic drived feed mechanism can quickly and efficiently put log in and remove bark then make wood get around. One set debarker can supply 2 set of veneer peeling machines .
It greatly saves the labor cost and the space.

plywood peeling machine manufacturer

meranti wood veneer machine

plywood making machine

hot press machine supplier for plywood


hot press machine manufacturer for plywood
